Agricultural Moulded REC Belts

Agricultural Moulded REC Belts

Features

  • Higher power transmission capacity over standard Belts.
  • Belts offer enhanced longitudinal flexibility due to specially designed cog profile.
  • Suitable for drives using smaller diameter pulleys at higher RPM.
  • Suitable for reverse bend drives.
  • The unique combination of lateral rigidity, which reduces the dishing effect, offers improved power transmission.
  • Anti-static, oil & heat resistant.
  • Specially compounded for significant performance, under variable speed conditions.
  • No bottom cracking/chipping is observed, as the Belt design is application-specific.
  • Low Belt-stretch due to the high tensile strength cords used in the Belt.
  • Temperature range: -25°C to +100°C.

Constructional Details

  1. Special fabric layer
  2. Cushion rubber compound.
  3. Specially treated & stabilized polyester cord
  4. Fibre-filled base compound
  5. Moulded cogs for better flexibility

Notes

Intermediate sizes are available upon request

Reference Standard

BS 3790, BS 3733: 1974, ASAE S211.3 & 4

Applications

Combine Harvester, Paper Industry, etc.
