Agricultural Wrap Belts

Agricultural Wrap Belts

Features

  • Special CR treated outer jacketing fabric for higher durability
  • Anti-static, oil and heat resistant
  • Maximum Belt linear speed (Classical section: Up to 30 m/Sec, Wedge section: up to 42 m/Sec, Narrow section: up to 45 m/Sec)
  • Temperature range: -30°C to +80°C

Constructional Details

  1. Wear-resistant bias-cut neoprene rubberised polyester cotton fabric
  2. High tensile cord embedding cushion rubber compound
  3. High tenacity, low stretch, specially treated polyester cords
  4. Especially compounded high modulus compression rubber

Notes

Intermediate sizes are available upon request

Reference Standard

BS 3790, BS 3733: 1974, ASAE S211.3 & 4

Applications

Combine harvesters, straw walker drives, threshing drives, agriculture tillers, rippers, etc.
