Automotive REC Belts

• Best suited for next-generation, high-speed engines.
• Cog profile offers enhanced flexibility and heat dissipation rate.
• Higher power transmission capacity, best suited for smaller diameter pulleys.
• Engineered and chemically treated with low stretch tensile cords for higher loads.
• Compounded for better grip and lateral rigidity.
• Excellent resistance to oil and heat.
• Suitable for HEMM (Heavy earthmoving machinery) applications.
• Temperature range: -25°C to +100°C and -45°C to +120°C in case of EPDM Belts.

Constructional Details

1. Specially designed top fabric for high resistance to wear and crack
2. Special high adhesion compound for improved dynamic adhesion performance
3. Specially treated polyester cord ensures minimal stretch of the belts
4. Fibre loaded compression compound for high power transmission and dimensional stability
5. Moulded cogged profile for superior flexibility and heat dissipation

Notes

Intermediate sizes are available upon request

Reference Standard

BS ISO-5287, DIN 7753-3, SAE J 636, JASO E 107

Applications

Automotive engines, alternators, compressors, water pumps, fans, power steering pumps, etc.
