Tractor Belts
Features
- Best suited for next-generation, high-speed engines
- Cog profile offers enhanced flexibility and heat dissipation rate
- Higher power transmission capacity, best suited for smaller diameter pulleys
- Engineered and chemically treated modulus & low stretch tensile cords for higher loads, without stretch
- Compounded for better grip and lateral rigidity
- Excellent resistance to oil and heat Suitable for HEMM (Heavy earthmoving machinery) applications
- Temperature range: -25°C to +100°C and -45°C to +120°C in case of EPDM Belts
Constructional Details
- Specially designed top fabric for high resistance to wear and crack
- Special high adhesion compound for improved dynamic adhesion performance
- Specially treated polyester cord ensures minimal stretch of the belts
- Fibre loaded compression compound for high power transmission and dimensional stability
- Moulded cogged profile for superior flexibility and heat dissipation
Notes
Intermediate sizes are available upon request
Reference Standard
BS ISO-5287, DIN 7753-3, SAE J 636, JASO E 107
Applications
High-temperature industrial drives, Compressors, Blowers, High power presses, Hot rolling mills, Textile machinery, ID fan, FD fans, Excavators, Pumps, Generators, Pulverisers, etc.
